• Active Transit /Cutting speeds 600/500 IPM
  • Mechanical home switches
  • X, Y and Z axis - Ball Screw
  • Power 220
  • Easy to use G-code controller
  • Anti Backlash
Router FeaturesSpecifications
Table Size42" x 48"
X,Y,Z Working Area24" x 36" x 6"
X,Y,Z, Traveling Position Accuracy+/-.002"
Frame StructureSteel
X.Y StructureBall Screw
Z StructureBall Screw
Max Speed0-400 IPM
Max Working Speed0-300 IPM
Spindle Power MotorHigh Frequency Conversion Water Cooled Motor
Working Mode24000v/min
Working VoltageAC220V
CommandIncludes MACH controller, G Code, dxf
InterfacePC
XY Working Tolerance< 0.02mm
SoftwareMach3, Type3 full function 3d
Packing Size49" x 46" x 32"
Net Weight390 lbs
